Topcon RL-SV2S - Example Grade Setup Procedure

7. Applied Operation and Setting of Various Functions
33
 Example of how to set up
When using the RL-SV2S after grade setting, it is necessary to accurately set the RL-SV2S
to the direction of grade setting.
Below is an example of how to set grades to the accurate grade setting direction. (To work
at Y-3% grade surface to the on-grade line)
ÌÓ¸°Ì
Grade to work
On-grade line
