Grade axes and axis symbols are as shown in the diagram below.
On the tripod set on level ground, grades will automatically level to approximately ±8%. When
setting larger grades, tilt the RL-SV2S towards the direction of the slope to maintain within the
auto leveling range. When exceeding the auto leveling range, the error message "Exceeding
leveling range" will be displayed.
C12. Error Display(p. 62)
+15%
Y axis X axis
-15%
-15%
+15%
Panel side
Minus
Plus
Minus
Minus
Plus
Plus
Minus
Plus
