7.
Applied Operat
ion and Settin
g of Various Funct
ions
45
1
Press the
key
.
2
Press the
or
key and select Sleep Mode ON/OFF (SLEEP), and press the
key
.
3
Press the
or
key to select ON/OFF
, and press the
key
. Setting is complete.
$
There are two ways to revert from t
he Sleep Mode.
•
Press one of the keys on RC-60
.
•
T
urn OFF
the power using the power key fo
r the RL-SV2S,
and turn the powe
r back on.
After reverti
ng from the
Sleep Mode, a
ll previous
settings are
maint
ained.
