3 Press the [ENT] key to complete the calibration.
The RC-300W display will return to the axis
selection screen.
If an axis remains to be checked, begin at step 4 of
“Checking Calibration”.
4 To complete the calibration procedure, press the
power switch to turn the instrument off.
In order to perform the Automatic grade setting more accurately, it is recommended that
the error be adjusted within ±2 mm.
If the correction value calculated exceeds the allowable range, the RC-300W will display
error code [CAL LIMIT]. Check the procedure again and perform any inspections and
adjustments.
X: Y:
Turn the instrument OFF to finish the
calibration.
