ASSEMBLY PROCEDURE
SECURING THE CHI
NREST BASE PLATE
1
Secure the chinr
est base plate to the unit type tab
le top with 2 scre
ws (8).
SECURING THE
BASE UNIT AND RAIL COVER
1
Align the wheel of the base un
it with the rail of the chinrest base pl
ate.
2
F
asten the r
ail cov
ers with 4 scre
ws (11): (2 screws each on th
e r
ight and lef
t sides).
Chinrest base plate
Rail cov
er
