ASSEMBLY PROCEDURE
2
Loosen the fixing screw on the outside of the fitting cavity of the illumination unit with a
screwdriv
er
. Align indices and slowly lower t
he illumination unit on to the shaft of the base
unit.
3
Fir
mly tighten
the fixing screw with a scre
wdriver
.
While assembling the illu
mination unit, take care not
to get y
our fingers caught.
T
o allow smooth rotation of the illumination
unit, mak
e sure yo
u do not f
asten the
scre
w too tightly
.
Indices
19
21
