ASSEMBLY PROCEDURE
SO-TM3
1
Align the locating pins of
SO-TM3 into the holes of the SL-D4Z microscope
, and f
asten the
two scr
ews.
2
The applanation to
nometer R900 type can be mounte
d on SO-TM3.
SO-TM4
1
Align the locating pins of
SO-TM4 into the holes of the SL-D4Z microscope
, and f
asten the
two scr
ews.
2
The applan
ation tonomete
r 870 type can be mounted on
SO-TM4.
The holes
Screws
Locating pins
Locating pins
Screws
22
24
