35
MAINTENANCE AND CHECKS
4
Pull off the soc
ke
t plug.
5
Pull out the lamp unit
.
6
Pull out the illumination
lamp from the soc
ket and replace
a ne
w lamp in the sock
et: T
ak
e
note of the soc
ket dir
ection.
7
Install the lamp unit and lamp
house cov
er in re
verse
order
.
Plug
So
cket
The notch of the illumination
lamp should f
ace the opp
osite
side from the cab
le.
35
37
