SPECIFICATIONS AND PERFORMANCE
SPECIFICATIONS AND PERFORMANCE
SPECIFICATION AND PERFORMANCE
SL-D2 SL-D4 SL-D4Z
Microscope unit
Type Galileo type
Magnification Drum, 3-step
magnification
Drum, 5-step
magnification
Manual zoom
Magnification steps 10, 16, 25 6, 10, 16, 25, 40 10, 16 and 25 w/clicks
Overall magnification (actual
vision field)
10.00 (
φ22.5mm)/
15.98 (
φ14.1mm)/
25.53 (
φ8.8mm)/
6.37 (
φ35.1mm)/
9.94 (
φ22.5mm)/
15.87 (
φ14.1mm)/
25.37 (
φ8.8mm)/
39.62 (
φ5.6mm)/
6.35 - 31.75
(
φ35.2 - φ7mm)
*10x, 16x and 25x
w/click
Eyepiece lens Magnification:12.5x
Diopter adjustment range:-5D - +3D -5D - +5D
Binocular tubes PD adjustment: 55 - 78mm
Illumination unit
Illumination field Slit width:0-14mm, can be altered gradually (14mm = circle)
Slit length:1-14mm, can be altered gradually (14mm = circle)
Aperture diameter:
φ14, 10, 5, 1, 0.3
Slit direction Can be altered gradually from vertical to horizontal
Side swing
Filter Blue filter, red-free filter, colour conversion filter, UV cut filter (normal use), IR cut filter
(normal use)
Illumination lamp 6V, 20W halogen lamp
Base unit
Forward-backward
movement
90mm
Right-left movement 100mm
Vertical movement 30mm
Fine movement forward-
backward/right-left
12mm
Chinrest unit
Vertical movement 80mm
Dimensions, Weight
Dimensions: w/Table 550mm(W)x399mm(D)x558mm(H)
w/Unit table 440mm(W)x379mm(D)x558mm(H)
w/o Table and Chinrest 329mm(W)x306mm(D)x415-445mm(H)
Weight: w/Table 17kg 17.5kg
w/Unit table 16kg 16.5kg
w/o Table and Chinrest 9.5kg 10kg
Table size 550mmx370mm
Unit Table size 440mmx350mm
Height from the table top to
patient’s eye
375mm
