CHAPTER 5– CONNECTING FIELD DEVICES TO THE I/O BOARD
47 MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
MultiLoad II AC Input Wiring
L
N
15A
I/O DIGITAL/
ANALOG
I/O 2 METER
METER 0 METER 1
PORT 8
PORT 8.N
PORT 8.N
PORT 8.L
PORT 8.L
PORT 8
PORT 8
PORT 8.L
PORT 8.N
L 1
✓
N 2
✓
L 3
N 4
IO_2M TB1
PORT
1.8
L 1
N 2
L 3
✓
N 4
✓
IO_2M TB1
PORT
0.8
L
N
L
N
L
N
Note: This shows a typical configuration. AC Permissive/Status inputs can be assigned to any unused AC input.
