CHAPTER 7– SERVICE AND REPAIR
78 MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
Overview Parts List and Part Numbers
The Toptech replacement part numbers are shown in the table below:
Part
Part Number
Part
Part Number
EXL Display Assembly
1667
AC Power Supply Board :
EXL Prox Card Reader
1669
Revision 1.0, 1.1
obsolete
EXL Keypad
1638
Revision 1.2
4728
EXL Keypad Barrier (1.1)
obsolete
DC Power Supply Board :
EXL Keypad Barrier (2.0)
2710
Revision 1.0, 1.1
obsolete
Revision 1.2
4729
Magnetic Switch Assembly
1900
I/O Board :
Magnetic Bolt Assembly
1901
Digital/ Analog I/O, revision 1.3
4718
Display Interface Cable
1250
2 Meter I/O Board, revision 1.2
4723
EXL backlight power cable
1663
CPU Board :
Revision 1.0, 2.0
obsolete
Revision 2.1
4727
