CHAPTER 7– SERVICE AND REPAIR
67 MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
Chapter 7 Service and Repair
Do not service MultiLoad II/ RCU II without disconnecting the supply circuit. Keep
the enclosure tightly closed while circuits are live.
Using a magnetic screwdriver is very helpful in retaining the screws during removal and
installation.
Overview and Subassemblies
Figure 7.1 MultiLoad II (ML II) / Remote Control Unit II (RCU II) Explosion Proof Lite Unit
Chapter
7
DISPLAY
DISPLAY
KEYPAD
CARD READER SLOT
