Feedback Controlyzer DigiLock 110
Page 66
Status: 5.12.17
11 Appendix
11.1 Environmental Conditions and Weight
Environmental requirements: Indoors, altitude < 2000 m
Operation temperature: +15 °C .. +30 °C
rel. humidity non condensing
Transport/storage temperature: 0 °C .. +40 °C
rel. humidity non condensing
Weight: 600 g
11.2 Internal Jumpers
The DigiLock 110 module is shipped with a standard configuration of its inputs and outputs. The internal
jumpers allow to modify this configuration. The table below shows all jumpers and their function. For loca-
tion of the jumpers and their positions please see Figure 57 and Figure 58.
Table 6 Baseboard jumper settings
Table 7 Plug-on-board jumper settings
Baseboard
Jumper Channel Pos 1-2 Pos 2-3 Factory
JP 7 DIO input output Pos 2-3
JP 8 AIO 1 output input Pos 2-3
JP 9 AIO 2 output input Pos 1-2
Jumper Channel Closed Open Factory
JP 300 DTC 110 T
set
connected to
#DA3
open
JP 301 not used open
JP 302 DCC 110 I
set
connected to
#DA1
open
JP 303 SC 110 out connected to
#DA2
closed
Plug-on board
Jumper Channel Pos 1-2 Pos 2-3 Open Factory
JP 2 Aux in 50 Ohm
terminated
connection to
Main in
high
impedance
Pos 1-2
JP 3 Precise in 50 Ohm
terminated
connection to
Main in
high
impedance
open
JP 5 Sum in 50 Ohm
terminated
connection to
Main in
high
impedance
Pos 1-2
Jumper Channel Closed Open Factory
JP 1 Main in 50 Ohm
terminated
high imped-
ance
closed
JP 4 not used open
