11.6 Pin Assignment of the DigiLock 110 Backplane
Actual pins needed for normal operation of the DigiLock 110 Module are marked with a grey back-
ground color. (VG-64-a/b/c standard connector according to IEC 60603-2)
Figure 59 VG-64-a/b/c standard connector
= lines connected on backplane
System GND 1a = 1c
Digital Signals (not used)
D #0 2a 2c D #1
D #2 3a 3c D #3
D #4 4a 4c D #5
D #6 5a 5c D #7
Analog Signals
DA #0 6a 6c DA #1
DA #2 7a 7c DA #3
Address Lines (not used)
A #0 10a 10c A #1
A #2 11a 11c A #3
A #4 12a 12c A #5
A #6 13a 13c A #7
read/write r/-w 14a 14c Address Enable AEN
Indicated Parameter
Photo Diode Channel 1 (DCC) 8a 8c (DCC) Photo Diode Channel 2
U
max
Channel 1 (DCC) 9a 9c (DCC) U
max
Channel 2
I(TEC)
max
Channel 1 (DTC) 15a 15c (DTC) I(TEC)
max
Channel 2
T
max
Channel 1 (DTC) 16a 16c (DTC) T
max
Channel 2
I
max
Channel 1 (DCC) 17a 17c (DCC) I
max
Channel 2
T
min
Channel 1 (DTC) 18a 18c (DTC) T
min
Channel 2
I
set
Channel 1 (DCC) 19a 19c (DCC) I
set
Channel 2
T
set
Channel 1 (DTC) 20a 20c (DTC) T
set
Channel 2
I
act
Channel 1 (DCC) 21a 21c (DCC) I
act
Channel 2
T
act
Channel 1 (DTC) 22a 22c (DTC) T
act
Channel 2
I
TEC
Channel 1 (DTC) 23a 23c (DTC) I
TEC
Channel 2
HV ON 24a = 24c HV ON
- Power (typ. 6.8 V GND) (floating if no
DCC 110/3A implemented)
25a = 25c - Power (typ. 6.8 V GND) (floating if
no DCC 110/3A implemented)
HV + Supply 26a = 26c HV + Supply
Error beep 27a 27c (Error LED on, when GND) Blink
Reference GND 28a 28c (Remote On/Off (low)) Power down
+ U
ref
29a 29c - U
ref
General supply lines
-15 V stabilized 30a = 30c
+15 V stabilized 31a = 31c
+ Power (typ. 6.8 V) (floating if no
DCC 110/3A implemented)
32a = 32c + Power (typ. 6.8 V) (floating if no
DCC 110/3A implemented)
