Flow Data Review
REVIEW MODE
Flow Data
VIEW EXCLUDED STATIONS
View (No Flow Only)
01 02 03 04 05 06 07 08
N N N N N N Y Y
1. With the Function dial in the REVIEW position, turn the Lower
Line knob to display Flow Data.
2. Turning the Upper Line knob right displays the Flow Data review
screens in the following sequence:
• Master Valve Status
• View Excluded Stations
• Flow Meter Status/Size
• Flow Meter K and Offset Value
• Flow Thresholds (GPM)
• Flow Delay (Minutes)
3. All Flow Review screens are self explanitory, with the exception of
View Excluded Stations. The initial screen provides a Skip/View
option. To review the stations excluded from flow monitoring, turn
the Lower Line knob to select View.
4. Turn the Upper Line knob right to display the first 8 stations.
Continue turning the knob right to display additional stations.
In the example above, station 7 and 8 are excluded from the flow
monitoring function.
To Next Page
