Figure42
•Lowerlinkpivot(4)(Figure43)
•Upperlinkpivot(4)(Figure43)
•Castorforkshaftbushings(2)(Figure44)
•Spindleshaftbearings(3)(Figure45)
•Idlerarmpivotbushings(2)(Figure45)
Figure43
Figure44
Figure45
34
