Seat-HeightandSeat-SlideButtons
Figure17
1.Seat-slidebuttons5.Seat-frameslidebar
2.Seat-heightbuttons
6.Weightcompensator
3.Seat-slidelever
7.Armrest-heightcontrol
4.Seat-rotationlever8.Lumbarknob(locatedon
theseatback)
•Seat-heightbuttons–usethemtoadjusttheseatpadup
ordown(Figure17).
•Seat-slidebuttons—usethemtoslidetheseatpad
forwardorrearward(Figure17).
Seat-Frame-SlideLeverandSeat-Base-SlideLever
•Seat-frame-slidelever—Usethislevertoadjustthe
entireseatandframeforwardorrearward(Figure17).
•Seat-base-slidelever—Usethislevertomovetheseat
baseforwardorrearwardontheseatframe(Figure17).
Seat-RotationLeverandSeat-WeightCompensator
•Seat-rotationlever—Usethislevertounlocktheseat
sothatyoucanrotatetheseattothedesiredposition.
Theseatwillrotate360°andlockintopositionat10°
increments(Figure17).
Note:RotatetheseattotheFrontpositionbefore
drivingthemachine.
•Seat-weightcompensator—Rotatethisleverforthe
weightcompensatortoadjusttheseatsupporttensionfor
theweightoftheoperator(Figure17).
–Rotatetheleverfortheweightcompensatorclockwise
toincreasethesupporttensionoftheseat.
–Rotatetheleverfortheweightcompensator
counterclockwisetoreducethesupporttensionof
theseat.
Armrest-HeightControl
Rotatethearmrest-heightcontroltoraiseorlowerthe
armrest(Figure17).
Seat-LumbarKnob
Rotatetheseat-lumbarknob,foundbehindtheseat,toadjust
thebacklumbarsupportforbestcomfort(Figure17).
SeatBelt
WARNING
Operatingthemachinewithouttherollover
protectionsystem(ROPS)securelyinplacecan
resultinseriousinjuryordeathifthemachinerolls
over.
•Ensurethattherollbarissecurelyinplace.
•AlwayswearaseatbeltwiththeROPSinplace.
•Ensurethattheoperatorseatisproperlysecured
tothemachine.
Note:Regulationsinsomelocalitiesrequirethatseatbeltson
constructionmachinesbe76mm(3inch)wide.Checkwith
localauthoritiesregardingtherequirementsforseatbelts.
•Tofastentheseatbelt,insertthetabendintotheleft
buckle.
Note:Ensurethatthetabendandthebuckleare
securelyfastened.
•Toreleasetheseatbelt,pushthebuttononthebuckle.
Battery-DisconnectSwitch
Thebattery-disconnectswitchislocatedbehindtheright
enginecowl(Figure18);useittoelectricallydisconnectthe
batteryfromthemachine.
21
