Figure60

1.Latchlever

3.Side-panellatch

2.Latchbutton

4.Liftthepanelupandthenawayfromthemachine

(Figure61).

Figure61

1.Latch

2.Sidepanel

InstallingtheSidePanels

1.Alignthesidepanelwiththemachineframe.

2.Alignthemountingboltatthetopofthesidepanel

withtheholeinthesupportangeofthehoodpanel

(Figure62).

Figure62

1.Hole(support

ange—hoodpanel)

3.Hoodpanel

2.Mountingbolt

4.Sidepanel

3.Applylightinwardpressureagainstthepanelat1of

thelatches.

4.Setthelatchbypushinginthelatchlever(Figure60).

5.Repeatsteps3and4attheotherlatch.

6.Ifthebackhoeisinstalledonthemachine,dothe

followingsubsteps:

A.Rotatethefrontendofthewalkwaytoitsoriginal

position(Figure59).

B.Aligntheholeinthewalkwaywiththeholeinthe

walkwaysupportbracket(Figure59).

C.Installtheretainingpinthroughtheholes.
