Figure90

FrontAxle

1.Front-axlehousing4.Pinionhousing

2.Oil-servicingequipment5.Sightport

3.Fillplug

Figure91

RearAxle

1.Rear-axlehousing4.Fillplug

2.Forward

5.Sightport

3.Oil-servicingequipment

6.Filltheaxleswiththespeciedoilthroughthesight

portuntiltheoilislevelwiththethreadsatthebottom

oftheport(Figure90andFigure91).

7.Waitafewminutesfortheoiltosettle,thenaddmore

oilasnecessary.

Note:Continuetoaddoiluntiltheoillevelstabilizes

andisatthebottomofthethreadsofthesightport.

8.Installthellplugsintothesightportsofthepinion

housingsfortheaxles(Figure90andFigure91).

CleaningtheAxleBreathers

ServiceInterval:Every1,000hours

1.Cleantheareaaroundthebreatherswithacleaning

solvent(Figure92andFigure93).

Figure92

1.Breathertting

2.Frontaxle
