6.Looselysecuretheright,rearrollbarassembly
totheright,rearframetubeusing1ange-head
bolt(3/8x2-1/4inches)and1locknut(3/8inch)
asshowninFigure36.
g364845
Figure36
7.Repeatstep6ontheleftside.
8.Looselysecuretherightrollbarconnector
assemblytotheright,rearrollbarassembly
using2hex-headbolts(3/8x1-1/4inches)and
2locknuts(3/8inch)asshowninFigure37.
g364840
Figure37
9.Repeatstep8ontheleftside.
