g398990

Figure67

LoweringtheCargoBed

WARNING

Theweightofthebedmaybeheavy.Hands

orotherbodypartscouldbecrushed.

Keepyourhandsandotherbodypartsaway

whenloweringthebed.

Slowlypushdownthecargobeduntilitlatches

securely.

OpeningtheTailgate

1.Ensurethatthecargobedisdownandlatched.

2.Usingbothhands,raisethetailgateusingthe

ridgenearthetopofthetailgate(Figure68).

g356658

Figure68

3.Lowerthetailgateuntilitisushwiththebottom

ofthecargobed(Figure69).

g356659

Figure69
