Torqeedo Cruise 3.0 R/T User Manual

62
DE EN
• Measure the required length of the TorqLink-Backbone.
• Measure the lengths of all required stub lines (cable connection between
component and TorqLink-Backbone).
• When planning, please note that TorqLink stub lines must not be extended.
If necessary, plan the TorqLink-Backbone so that the components can be
connected through the TorqLink stub line without an extension. If necessary,
extend the TorqLink-Backbone to connect a component that is far away; you
can nd corresponding extensions in our accessories catalogue.
• Cables must be xed every 400 mm, plan attachment material. In places
where fastening is not possible, a scuff guard must be tted.
• Openly laid cables (e.g. inatable boat) must be protected with chang
protection, plan sufcient material.
• When planning, please note not to bundle power cables with data or anten-
na cables (e.g. radios) for other loads.
• Observe the minimum bending radii of the cables when planning.
• If a second earthed onboard power system is available, ensure that both
systems use a common earthing point.
• Live parts must be tted or installed with protection against accidental
contact; the necessary installation space must be taken into account during
the planning stage.
6.3 Tools, equipment and material
Tool Used for
Spanner SW13 or socket wrench
SW13
Battery cable to battery terminals
Socket wrench SW17 Anode replacement
Spanner SW13 or socket wrench
SW13
Attaching the transom bracket to the
transom;
Hexagon socket size 6 Motor locking screw
Spanner SW17 or socket wrench
SW17
Propeller assembly
Torque key Fastening screws and nuts
Lubricant, if necessary salt water
resistant for salt water use
Mounting the remote steering system
and maintenance work
Tool Used for
Drill bit 8.5 mm Preparing the transom mounting
Sealant Sealing the drill holes in the transom
Cable ties in various sizes Cable routing and mounting
M5 mounting screws, length as
required
Installing the battery main switch
M5 mounting screws, length as
required
Installing the charger unit
M6 mounting screws, length as
required
Installing the fast charger
M6 mounting screws, length as
required
Installing the accelerator lever
Attachment material Attaching the power cable and data
cable
Abrasion protection Installing/routing power cables
Earthing cable 25 mm² cross-section Installing the earthing cable
