Toshiba e-STUDIO203 Service Handbook

e-STUDIO163/203 PREVENTIVE MAINTENANCE (PM) December 2005 © TOSHIBA TEC
4 - 12
4.4 PM KIT
Item Product name Part name Qty.
DEV-KIT-2340 Developer material D-2320 1
Drum cleaning blade BL-2320D 1
Separation finger for drum SCRAPER-371 2
Recovery blade BLADE-REC 1
Main charger grid GRID-CH-M-371 1
Needle electrode CH-M 1
Transfer charger wire WIRE-CH-060-353-R 1
Separation charger wire WIRE-CH-060-353-R 1
FR-KIT-1640 Ozone filter FILTER-OZON-TRU-371 1
Fuser roller HR-1640-U 1
Pressure roller HR-1640-L 1
Separation finger for fuser roller SCRAPER-280 5
Bush for fuser roller BUSH-HR/RLR 2
DF-KIT-3018 Pickup roller ASYS-ROL-FEED 1
Feed roller ASYS-ROL-FEED 1
Separation roller ASYS-ROL-RET 1
