December 2005 © TOSHIBA TEC e-STUDIO163/203 ADJUSTMENT
3 - 3
3
3.2 Image Dimensional Adjustment
3.2.1 General description
There are several adjustment items in the image dimensional adjustment, as listed below. When adjust-
ing these items, the following adjustment order should strictly be observed.
Item to be adjusted Code in mode 05
1 Paper alignment at the registration roller 450, 451, 458, 460, 461, 462,
463, 464
2 Printer related
adjustment
(a) Reproduction ratio of primary scanning direction
(Fine adjustment of polygonal motor rotation
speed)
401
(b) Primary scanning data laser writing start position 411
(c) Reproduction ratio of secondary scanning direc-
tion
(Fine adjustment of main motor rotation speed)
421
(d) Secondary scanning data laser writing start posi-
tion
441, 440, 442
3 Scanner related
adjustment
(a) Reproduction ratio of primary scanning direction 405
(b) Image location of primary scanning direction 306
(c) Reproduction ratio of secondary scanning direc-
tion
340
(d) Image location of secondary scanning direction 305
(e) Top margin 430
(f) Right margin 432
(g) Bottom margin 433
06/04
To Next Page
