e-STUDIO163/203 TROUBLESHOOTING December 2005 © TOSHIBA TEC
5 - 2
Relation between the jamming area and the corresponding sensors and covers
(If a jam is occurring in the PFU, check the PFU board.)
[E03] Paper remaining inside the equipment at power-ON
Open the cover of the unit/area whose picture is blinking on the control panel. Is there any
paper on the transport path? (Refer to the following table.)
%
YES # Remove the paper.
NO
Is the sensor in the jamming area working? (Perform the input check in the test mode: refer
to the following table.)
l
l
l
l
l
l
l
l
%
NO # 1) Check if the connector of the sensor is disconnected.
2) Check if any of the connectors on the MAIN board is disconnected.
3) Check if the connector pins are disconnected and the harnesses are
open circuited.
4) Check if the conductor pattern on the MAIN board is short circuited or
open circuited.
5) Replace the sensor.
6) Replace the MAIN board.
YES
Replace the MAIN board.
Jamming area Cover Sensor Test mode / Input check
Registration area Transfer cover Registration sensor 03-[INTERRUPT]OFF/[9]/[6]
Exit area Transfer cover Exit sensor 03-[INTERRUPT]OFF/[9]/[5]
PFU PFU side cover PFU feed sensor 03-[INTERRUPT]OFF/[7]/[5]
To Next Page
