e-STUDIO163/203 ERROR CODE AND SELF-DIAGNOSTIC MODE December 2005 © TOSHIBA TEC
2 - 6
OFF [7]
0 - - -
1 - - -
2 - - -
3 - - -
4 - - -
5 PFU feed sensor Paper present No paper
6 PFU drawer detection switch No drawer Drawer present
OFF [8]
0 - - -
1 - - -
2 Polygonal motor rotation status (Motor is
rotating at Output Mode (04))
Abnormal rota-
tion
Normal rotation
3 - - -
4 PFU board connection Not connected Connected
5 - - -
6 24 V power supply
(Front cover opening/closing)
24 V ON 24 V OFF
OFF [9]
0 - - -
1 - - -
2 PFU cover opening/closing switch Cover opened Cover closed
3 Front cover opening/closing switch Cover opened Cover closed
4 - - -
5 Exit sensor Paper present No paper
6 Registration sensor Paper present No paper
OFF [0]
0 - - -
1 - - -
2 - - -
3 Developer unit switch Not connected Connected
4 Fuser unit switch Connected Not connected
5 - - -
6 Externally counter connection Not connected Connected
[INTER
RUPT]
LED
Number
[Digital
keys]
Display
position
of the
density
LED
Items to check ON OFF
06/02
To Next Page
