Test Program for Field.
Subtest 05 640 * 200 Character Display
This subtest uses 640*200 video resolution to display three windows, each
window drives a different set of dots: even dots, odd dots and all dots. The
screen below displays when this subtest is executed.
30 Qosmio X500
Maintenance Manual (960-Q08)
Press ENTER to display the following 16 colors: black, blue, green, cyan,
red, magenta, brown, white, dark gray, light blue, light green, light cyan, light
red, light magenta, yellow, and intensified white.
640 * 200 GRAPHICS DISPLAY : [ 6 ]
EVEN DOTS ODD DOTS ALL DOTS
DRIVEN DRIVEN DRIVEN
640*200 GRAPHICS DISPLAY : [ E ]
BLACK DARK GRAY
BLUE LIGHT BLUE
GREEN LIGHT GREEN
CYAN LIGHT CYAN
RED LIGHT RED
MAGENTA LIGHT MAGENTA
BROWN YELLOW
WHITE INTENSIFIED WHITE
Press [Enter] KEY
To exit this subtest and return to the Display Test menu:
Press Enter if NO was selected for Test Loop on the Test Parameter Menu.
Press Ctrl + break if YES was selected for Test Loop on the Test Parameter
Menu.
