Toshiba Qosmio X500 Maintenance Manual

Replacement Procedures
Qosmio X500 Maintenance Manual (960-Q08) 4-30
Installing the keyboard
The following describes the procedure for installing the keyboard.
1. Turn the keyboard upside down and place it on the palm rest as its face down.
Connect the keyboard flexible cable to the connector on the system board.
2. Slide and set the speaker cover assembly and secure it with the following screw.
 M2.53.0B FLAT BIND screw x4
3. Install the keyboard brace by pressing it from the topside.

Toshiba Qosmio X500 Specifications

General

Graphics	NVIDIA GeForce GTS 360M
Display Size	18.4 inches
Resolution	1920 x 1080 pixels
Storage	500GB HDD
Operating System	Windows 7 Home Premium
LAN	Gigabit Ethernet
USB Ports	4 x USB 2.0
HDMI	Yes
Processor	Intel Core i7
Optical Drive	Blu-ray Disc drive
Wireless	Wi-Fi 802.11n
Battery	Lithium-ion battery (various capacities)
Weight	10.1 lbs
RAM	Up to 8GB DDR3
