Appendix C Pin Assignment
CN11 LCD Panel Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 VIN --- 2 LCDVCC ---
3 VIN --- 4 LCDVCC ---
5 VIN --- 6 LCD-EDIDDATA I/O
7 +3V --- 8 LCD_EDIDCLK I/O
9 CCD _POWER --- 10 LVDS_VADG I/O
11 MIC_GND --- 12 GND ---
13 INT_MIC_R I/O 14 USBP3+_LCD I/O
15 DISPON --- 16 USBP3-_LCD I/O
17 GND --- 18 GND ---
19 LCD_TXLCLKOUT+ I/O 20 LCD_TXUCLKOUT+ I/O
21 LCD_TXLCLKOUT- I/O 22 LCD_TXUCLKOUT- I/O
23 GND --- 24 GND ---
25 LCD_TXLOUT0+ I/O 26 LCD_TXUOUT0+ I/O
27 LCD_TXLOUT0- I/O 28 LCD_TXUOUT0- I/O
29 GND --- 30 GND ---
31 LCD_TXLOUT1+ I/O 32 LCD_TXUOUT1+ I/O
33 LCD_TXLOUT1- I/O 34 LCD_TXUOUT1- I/O
35 GND --- 36 GND ---
37 LCD_TXLOUT2+ I/O 38 LCD_TXUOUT2+ I/O
39 LCD_TXLOUT2- I/O 40 LCD_TXUOUT2- I/O
41 GND --- 42 GND ---
