Toshiba Qosmio X500 Maintenance Manual

Test Program for Field.
3.2 Executing the Diagnostic Test
DOS is required to run the Diagnostics Program. To start the programs follow these steps:
1. Create a DOS bootable disk and copy all the files from the Tests and Diagnostics
software to the disk.
2. Insert the boot disk into the computer’s floppy disk drive and turn on the computer.
NOTES: If error message display “Sorry. This Model Type Not Match This Machine”:
Please Check :
1. You test disk is match this model , ex. disk is 14” but machine is 13” .
2. The M/B EEPROM project type is math your test disk , if not , please use WDMI3.EXE
to modify with right LCD size .
The following screen displays:
4 Qosmio X500 Maintenance Manual (960-Q08)
::Select item
ESC :Escape
[ DIAGNOSTICS MENU ]
01.DIAGNOSTIC TEST
02.RUNNING TEST
03.DMI INFORMATION
04.LOG UTILITIES
05.SYSTEM CONFIGURATION
06.OPTION
99.EXIT
TOSHIBA Satellite(Pro) P500 Diagnostics
Version v1.10
3. To select the Diagnostic Test from the Diagnostics Menu use the arrow keys to set the
highlight bar to 01 and press Enter.

Toshiba Qosmio X500 Specifications

General

Graphics	NVIDIA GeForce GTS 360M
Display Size	18.4 inches
Resolution	1920 x 1080 pixels
Storage	500GB HDD
Operating System	Windows 7 Home Premium
LAN	Gigabit Ethernet
USB Ports	4 x USB 2.0
HDMI	Yes
Processor	Intel Core i7
Optical Drive	Blu-ray Disc drive
Wireless	Wi-Fi 802.11n
Battery	Lithium-ion battery (various capacities)
Weight	10.1 lbs
RAM	Up to 8GB DDR3
