Chapter 1 Hardware Overview
1.6 TFT Color Display
The Qosmio X500 Ganel use CCFL to control backlight.
1.6.1 LCD Module with CCFL Backlight
Figure 1-6-1 shows a view of the LCD module and Table 1-6-2 lists the specifications.
Figure 1-6-1 SAMSUNG LCD Module
17
Qosmio X500
Maintenance Manual (960-Q08)
