Toshiba Qosmio X500 Maintenance Manual

Replacement Procedures
Qosmio X500 Maintenance Manual (960-Q08) 4-25
4.8 Memory module
CAUTION: The power of the computer must be turned off when you remove a memory
module. Remove a memory module with the power on risks damaging the
module or the computer itself.
Do not touch memory module terminals. Any dirt on the terminals may cause
memory access problems.
Never press hard or bend a memory module.
Removing a memory module
To remove a memory module, confirm that the computer is in boot mode. Then perform the
following procedure (See Figure 4-8-1 to 4-8-2).
1. Loose the screw securing the memory slot cover.
 M2.54.0B FLAT BIND screw x3
2. Remove the memory slot cover.
3. Open the left and right latches and remove a memory module.

Toshiba Qosmio X500 Specifications

General

Graphics	NVIDIA GeForce GTS 360M
Display Size	18.4 inches
Resolution	1920 x 1080 pixels
Storage	500GB HDD
Operating System	Windows 7 Home Premium
LAN	Gigabit Ethernet
USB Ports	4 x USB 2.0
HDMI	Yes
Processor	Intel Core i7
Optical Drive	Blu-ray Disc drive
Wireless	Wi-Fi 802.11n
Battery	Lithium-ion battery (various capacities)
Weight	10.1 lbs
RAM	Up to 8GB DDR3
