Replacement Procedures
4.3 PC card
Removing a PC card
The following describes the procedure for removing a PC card (See Figure 4-3-1).
CAUTION: Insert or remove a PC card in accordance with any instructions in a PC card
manual or the manuals of the computer system you are using.
1. Push the PC card. It will pop out PCMCIA Card when you release it. And NEW
Card same as PC card. Then press the card once more to eject a card.
2. Grasp one of PC card and remove it.
NOTE: If a PC card is not inserted all the way, the eject button may not pop out. Be
sure to push a PC card firmly and press the eject button again.
Figure 4-3-1
Remove a PC card
Installing a PC card
The following describes the procedure for inserting a PC card (See Figure 4-3-2).
Qosmio X500 Maintenance Manual (960-Q08) 4-10
