Troubleshooting Procedures
Qosmio X500
Maintenance Manual (960-Q08)
39
Procedure 2 Replacement Check
If External microphone/Headphone does not work properly, perform check 1.
If Internal microphone /Speaker does not work properly, perform check 2.
If HP out does not work properly, perform check 3.
If Volume control does not work properly, perform check 4.
Check 1 External microphone/Headphone may be faulty. Replace it with a new one
following the steps in Chapter 4. If the problem still occurs, perform Check 5.
Check 2 Internal microphone /Speaker may be faulty. Replace it with a new one following
the steps in Chapter 4. If the problem still occurs, perform Check 5.
Check 3 HP out may be faulty. Replace it with a new one following the steps in Chapter 4.
If the problem still occurs, perform Check 5.
Check 4 Volume control may be faulty. Replace it with a new one following the steps in
Chapter 4. If the problem still occurs, perform Check 6.
Check 5 Flat cable between AD board/Speaker and system board may be faulty. Replace it
with new cable following the instructions in Chapter 4. If the problem still occurs,
perform Check 6.
Check 6 Audio board/System board may be faulty. Replace it with a new one following the
instructions in Chapter 4.
To Next Page
