Toshiba Qosmio X500

Replacement Procedures
Qosmio X500 Maintenance Manual (960-Q08) 4-24
Installing Second HDD-H9.5mm / HDD-H12.5mm
The following describes the procedure for installing a HDD.
1. Install a HDD to the HDD holder and secure it with the following screws.
 M3.03.5F FLAT BIND screw x4
NOTE: Although they are 3mm head screws, screw torque must be set in 2.5kg-cm for
four screws securing the HDD holder.
2. Insert the HDD assembly into the HDD slot and connect it carefully to the MAIN
HDD on the system board.
3. Secure the HDD assembly with the following screw.
 M2.53.0B FLAT BIND screw x2
 M2.54.0B FLAT BIND screw x2
