Toshiba Qosmio X500

Pin Assignment
Qosmio X500 Maintenance Manual (960-Q08)
2
CN24 MMB Connector
PIN No. Signal name I/O PIN No. Signal name I/O
1 +3VPCU --- 2 +5VPCU ---
3 KEY_INT I 4 GND ---
5 3ND_MBDATA I/O 6 3ND_MBCLK I/O
CN20 Keyboard LED Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 +5V --- 2 BOARD_DI5 O
3 KB_LED_DET# --- 4 KB_LED I
CN13 Power Board Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 +5VPCU I 2 NBSWON# I
3 PWRLED# I 4 GND ---
CN16 Keyboard Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 K_LED_P --- 2 MY16 O
3 --- --- 4 MX17 O
5 --- --- 6 K_LED_P ---
