Toshiba Qosmio X500

Pin Assignment
Qosmio X500 Maintenance Manual (960-Q08)
3
7 MY2 O 8 MY1 O
9 MY0 O 10 MY4 O
11 MY3 O 12 MY5 O
13 MY14 O 14 MY6 O
15 MY7_K O 16 MY3_K O
17 MY7 O 18 MY9 O
19 MY10 O 20 MY11 O
21 MY12 O 22 MY15 O
23 MX7 O 24 MX2 O
25 MX3 O 26 MX4 O
27 MX0 O 28 MX5 O
29 MX6 O 30 MX1 O
31 K_LED_P O 32 CAPSLED O
33 FN_F10 O 34 NUMLED O
CN21 Touchpad & Fingerprint Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 +5V TP --- 2 TPDATA I/O
3 TPCLK I/O 4 LED_ON# I/O
5 GND --- 6 USBP1+ I/O
7 USBP1- I/O 8 GND ---
9 TP_ON_OFF O 10 +3V ---
CN18 Felica Connectors
