Toshiba Qosmio X500

Board Layout
<Back layout>
01
B-8 Qosmio X500 Maintenance Manual (960-Q08)
02
Figure B-3-3 Finger Print Board layout (Back)
Table B-3-4 Finger Print Board connectors
Location Function
(01) CN2 Finger Print Board to TP Board connector
(02) CN3 Finger Print Board to TP Board connector
