Toshiba Qosmio X500 Maintenance Manual

Replacement Procedures
Qosmio X500 Maintenance Manual (960-Q08) 4-15
Installing SSD/MAIN HDD-H9.5mm / HDD-H12.5 mm
The following describes the procedure for installing the main HDD.
1. Install a SSD/HDD to the SSD/HDD holder and secure it with the following screws.
 M3.03.0B FLAT BIND screw x4
NOTE: Although they are 3mm head screws, screw torque must be set in 2.5kg-cm for
four screws securing the HDD holder.
2. Insert the SSD/HDD assembly into the SSD/HDD slot and connect it carefully to the
SSD/MAIN HDD on the system board.
3. Secure the SSD/HDD assembly with the following screw.
 M2.53.0B FLAT BIND screw x2
 M2.54.0B FLAT BIND screw x2

Toshiba Qosmio X500 Specifications

General

Graphics	NVIDIA GeForce GTS 360M
Display Size	18.4 inches
Resolution	1920 x 1080 pixels
Storage	500GB HDD
Operating System	Windows 7 Home Premium
LAN	Gigabit Ethernet
USB Ports	4 x USB 2.0
HDMI	Yes
Processor	Intel Core i7
Optical Drive	Blu-ray Disc drive
Wireless	Wi-Fi 802.11n
Battery	Lithium-ion battery (various capacities)
Weight	10.1 lbs
RAM	Up to 8GB DDR3
