Replacement Procedures
Qosmio X500 Maintenance Manual (960-Q08) 4-36
Installing a TV Tuner card
The following describes the procedure for installing a TV tuner card.
1. Insert a TV tuner card terminals slantwise into the connector on the computer and
press a TV tuner card and lock the secure screws.
2. Connect the TV antenna cable to the terminals on a TV tuner card.
3. Put the TV antenna cable on the right location from the guide(see Figure 4-10-3)
4. Secure TV tuner card with the following screws
2.5.0 x 3.0B BIND screw x2
