Table 3: Inverter Status 1 (register 0F)
Lower
Byte
Bit Inverter Status 0 1 Single-Bit
Read Mask
bit 0 running (acc/dec)  running 0001
bit 1 unused (always 0)   
bit 2 forward / reverse reverse forward 0004
bit 3 acc/dec #1/#2 acc/dec #1 acc/dec #2 0008
bit 4 for inverter use   
bit 5 for inverter use   
bit 6 for inverter use   
bit 7 jog/normal mode normal (acc/dec) jog mode 0080
Upper
Byte
Bit Inverter Status 0 1 Single-Bit
Read Mask
bit 0 feedback ON/OFF OFF feedback active 0001
bit 1 DC inj. braking OFF DC inj. braking active 0002
bit 2 V/F #1/#2 V/F #1 V/F #2 0004
bit 3 coasting not coasting coasting 0008
bit 4 emergency off not in emergency off in emergency off 0010
bit 5 for inverter use   
bit 6 for inverter use   
bit 7 for inverter use   
Table 4: Inverter Typeform Codes
230v Class 460v Class 575v Class
Inverter
Model
Typeform
Data (Hex)
Inverter
Model
Typeform
Data (Hex)
Inverter
Model
Typeform
Data (Hex)
G3-2010 ××21 G3-4015 ××42 G3-6060 ××65
G3-2015 ××22 G3-4025 ××43 G3-6120 ××67
G3-2025 ××23 G3-4035 ××44 G3-6160 ××68
G3-2035 ××24 G3-4055 ××45 G3-6220 ××69
G3-2055 ××25 G3-4080 ××46 G3-6270 ××6A
G3-2080 ××26 G3-4110 ××47 G3-6330 ××6B
G3-2110 ××27 G3-4160 ××48 G3-6400 ××6C
G3-2160 ××28 G3-4220 ××49 G3-6500 ××6D
G3-2220 ××29 G3-4270 ××4A G3-6600 ××6E
G3-2270 ××2A G3-4330 ××4B G3-6750 ××6F
G3-2330 ××2B G3-4400 ××4C G3-610K ××70
G3-2400 ××2C G3-4500 ××4D G3-612K ××71
G3-4600 ××4E G3-615K ××72
G3-4750 ××4F G3-620K ××73
G3-410K ××50
G3-412K ××51
G3-415K ××52
G3-420K ××53
G3-425K ××54
G3-430K ××55
