25
Table 1: Input Terminal Status Monitor (register 0D)
Lower
Byte
Bit Input
Terminal
0 1 Single-Bit
Read Mask
bit 0 F terminal - CC open terminal - CC shorted 0001
bit 1 R terminal - CC open terminal - CC shorted 0002
bit 2 S1 terminal - CC open terminal - CC shorted 0004
bit 3 S2 terminal - CC open terminal - CC shorted 0008
bit 4 S3 terminal - CC open terminal - CC shorted 0010
bit 5 S4 terminal - CC open terminal - CC shorted 0020
bit 6 S5 (option) terminal - CC open terminal - CC shorted 0040
bit 7 S6 (option) terminal - CC open terminal - CC shorted 0080
Upper
Byte
Bit Input Terminal 0 1 Single-Bit
Read Mask
bit 0 unused (always 0)   
bit 1 unused (always 0)   
bit 2 unused (always 0)   
bit 3 unused (always 0)   
bit 4 unused (always 0)   
bit 5 S7 (option) terminal - CC open terminal - CC shorted 0020
bit 6 RES terminal - CC open terminal - CC shorted 0040
bit 7 ST terminal - CC open terminal - CC shorted 0080
Table 2: Output Terminal Status Monitor / Inverter Status 2 (register 0E)
Lower
Byte
Bit Output Terminal 0 1 Single-Bit
Read Mask
bit 0 unused (always 0)   
bit 1 unused (always 0)   
bit 2 FAN OFF ON 0004
bit 3 FL FLB-FLC shorted FLA-FLC shorted 0008
bit 4 MS relay OFF ON 0010
bit 5 OUT (option) OUTB-OUTC shorted OUTA-OUTC shorted 0020
bit 6 RCH RCHA -RCHC open RCHA -RCHC shorted 0040
bit 7 LOW LOWA-LOWC open LOWA-LOWC shorted 0080
Upper
Byte
Bit Inverter Status 0 1 Single-Bit
Read Mask
bit 0 accelerating not accelerating accelerating 0001
bit 1 decelerating not decelerating decelerating 0002
bit 2 for inverter use   
bit 3 retry not retrying retrying 0008
bit 4 running (including DC
injection braking)
stopped running 0010
bit 5 for inverter use   
bit 6 for inverter use   
bit 7 tripped not tripped tripped 0080
