Toshiba TOSVERT VF-PS1 User Manual

K-6
E6581386
11
[3] Terminal function selection Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0110 Always ON function selection 1 0~135 *1 1/1 6 Disabled ●/● ● ● 6. 3. 1
 0111 Input terminal function selection 1 (F) 0~135 *1 1/1 2 Disabled ●/● ● ● 7. 2. 1
 0112 Input terminal function selection 2 (R) 0~135 *1 1/1 4 Disabled ●/● ● ● 7. 2. 1
 0114 Input terminal function selection 4 (RES) 0~135 *1 1/1 8 Disabled ●/● ● ● 7. 2. 1
 0115 Input terminal function selection 5 (S1) 0~135 *1 1/1 10 Disabled ●/● ● ● 7. 2. 1
 0116 Input terminal function selection 6 (S2) 0~135 *1 1/1 12 Disabled ●/● ● ● 7. 2. 1
 0117 Input terminal function selection 7 (S3) 0~135 *1 1/1 14 Disabled ●/● ● ● 7. 2. 1
 0118 Input terminal function selection 8 (RR/S4) 0~135 *1 1/1 16 Disabled ●/● ● ● 7. 2. 1
 0119 Input terminal function selection 9 (LI1) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0120 Input terminal function selection 10 (LI2) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0121 Input terminal selection 11 (LI3) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0122 Input terminal selection 12 (LI4) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0123 Input terminal selection 13 (LI5) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0124 Input terminal selection 14 (LI6) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0125 Input terminal selection 15 (LI7) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0126 Input terminal selection 16 (LI8) 0~135 *1 1/1 0 Disabled ●/● ● ● 7. 2. 1
 0127 Always ON function selection 2 0~135 *1 1/1 0 Disabled ●/● ● ● 6. 3. 1
 0128 Always ON function selection 3 0~135 *1 1/1 0 Disabled ●/● ● ● 6. 3. 1
 0130 Output terminal function selection 1 (OUT1) 0~255 *2 1/1 4 Disabled ●/● ● ● 7. 2. 2
 0131 Output terminal function selection 2 (OUT2) 0~255 *2 1/1 6 Disabled ●/● ● ● 7. 2. 2
 0132 Output terminal function selection 3 (FL) 0~255 *2 1/1 10 Disabled ●/● ● ● 7. 2. 2
 0133 Output terminal function selection 4 (OUT3) 0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
 0134 Output terminal function selection 5 (OUT4) 0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
 0135 Output terminal function selection 6 (R1) 0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
 0136 Output terminal function selection 7 (OUT5) 0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
 0137 Output terminal function selection 8 (OUT6) 0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
 0138 Output terminal function selection 9 (R2) 0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
*1:  For the adjustment range, see the table on page K-38.
*2:  For the adjustment range, see the table on page K-39.
