Toshiba TOSVERT VF-PS1 User Manual

K-7
E6581386
11
[4] Terminal response time setup Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0168
Output terminal function selection 10 (R3)
*1
0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
 0169
Output terminal function selection 11 (R4)
*1
0~255 *2 1/1 254 Disabled ●/● ● ● 7. 2. 2
 0170 Base frequency 2 25.0~500.0 Hz 0.1/0.01 *4 Disabled - - ● 6. 4. 1
 0171 Base frequency voltage 2 50~330V/660V 1/0.1 *3 Disabled - - ● 6. 4. 1
 0172 Manual torque boost 2 0.0~30.0% 0.1/0.1 *3 Enabled - - ● 6. 4. 1
 0173
Thermal protection level 2
10~100% 1/1 100 Enabled - - ● 6. 4. 1
*1: Unsupported option
*2:  For the adjustment range, see the table on page K-39.
*3: Default values vary depending on the capacity.  See the table of K-42.
*4: Inverter with a model number ending with -WN: 60.0 -WP: 50.0
[5] V/f 5-point setting Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0190 V/f 5-point setting VF1 frequency 0.0~ Hz 0.1/0.01 0.0 Disabled - - ● 5. 6
 0191 V/f 5-point setting VF1 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● 5. 6
 0192 V/f 5-point setting VF2 frequency 0.0~ Hz 0.1/0.01 0.0 Disabled - - ● 5. 6
 0193 V/f 5-point setting VF2 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● 5. 6
 0194 V/f 5-point setting VF3 frequency 0.0~ Hz 0.1/0.01 0.0 Disabled - - ● 5. 6
 0195 V/f 5-point setting VF3 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● 5. 6
 0196 V/f 5-point setting VF4 frequency 0.0~ Hz 0.1/0.01 0.0 Disabled - - ● 5. 6
 0197 V/f 5-point setting VF4 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● 5. 6
 0198 V/f 5-point setting VF5 frequency 0.0~ Hz 0.1/0.01 0.0 Disabled - - ● 5. 6
 0199 V/f 5-point setting VF5 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● 5. 6
[6] Speed/torque reference gain/bias setup [1/3] Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0200 Frequency priority selection
0:/ terminal switching (input
terminal function selection 104, 105)
1:/ frequency switching (switching
with )
1/1 0 Enabled ●/● ● ● 6. 6. 1
 0201 VI/II input point 1 setting 0~100% 1/1 0 Enabled ●/● ● ● 7. 3. 2
 0202 VI/II input point 1 frequency 0.0~ Hz 0.1/0.01 0.0 Enabled ●/● ● ● 7. 3. 2
