Toshiba TOSVERT VF-PS1 User Manual

K-9
E6581386
11
[6] Speed/torque reference gain/bias setup [3/3] Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0230 AI2 input point 2 setting 0~100% 1/1 100 Enabled ●/● ● ● *2
 0231 AI2 input point 2 frequency 0.0~ Hz 0.1/0.01 *1 Enabled ●/● ● ● *2
 0234 RP/high speed pulse input point 1 setting 0~100% 1/1 0 Enabled ●/● ● ● *3
 0235
RP/high speed pulse input point 1
frequency
0.0~ Hz 0.1/0.01 0.0 Enabled ●/● ● ● *3
 0236 RP/high speed pulse input point 2 setting 0~100% 1/1 100 Enabled ●/● ● ● *3
 0237
RP/high speed pulse input point 2
frequency
0.0~ Hz 0.1/0.01 *1 Enabled ●/● ● ● *3
*1: Inverter with a model number ending with -WN: 60.0 -WP: 50.0
*2:  For details, refer to Instruction Manual (E6581341) specified in Section 6.36.
*3:  For details, refer to Instruction Manual (E6581319) specified in Section 6.36.
[7] Operation frequency Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0240 Starting frequency setting 0.0~10.0Hz 0.1/0.01 0.1 Enabled ●/● ● ● 6. 7. 1
 0241 Operation start frequency 0.0~ Hz 0.1/0.01 0.0 Enabled ●/● ● ● 6. 7. 2
 0242 Operation start frequency hysteresis 0.0~30.0Hz 0.1/0.01 0.0 Enabled ●/● ● ● 6. 7. 2
 0243 Stop frequency setting 0.0~30.0Hz 0.1/0.01 0.0 Enabled ●/● ● ● 6. 7. 1
 0244 Frequency command dead band 0.0~5.0Hz 0.1/0.01 0.0 Enabled ●/● ● ● 6. 7. 3
[8] DC braking Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0250 DC braking start frequency 0.0~120.0Hz 0.1/0.01 0.0 Enabled ●/● ● ● 6. 8. 1
 0251 DC braking current 0~100% 1/1 50 Enabled ●/● ● ● 6. 8. 1
 0252 DC braking time 0.0~20.0 sec. 0.1/0.1 1.0 Enabled ●/● ● ● 6. 8. 1
 0253 Forward/reverse DC braking priority control
0:Disabled
1:Enabled
1/1 0 Enabled ●/● ● ● 6. 8. 1
 0254 Motor shaft fixing control
0:Disabled
1:Enabled
1/1 0 Enabled ●/● ● ● 6. 8. 2
 0255 0Hz command output selection
0:Default (DC braking)
1:0Hz command
1/1 0 Enabled -/● ● ● 6. 8. 3
 0256
Time limit for lower-limit frequency
operation
0.0:Disabled, 0.1~600.0 sec. 0.1/0.1 0.0 Enabled ●/● ● ● 6. 9
