Toshiba TOSVERT VF-PS1 User Manual

K-18
E6581386
11
[23] Protection functions [2/4] Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Constant Reference
 0606 OL reduction starting frequency 0.0~60.0Hz 0.1/0.01 6.0 Enabled ●/● ● ● 5. 14
 0608 Input phase failure detection mode selection
0:Disabled
1:Enabled
1/1 1 Disabled ●/● ● ● 6. 26. 6
 0609 Low current detection hysteresis width 1~20% 1/1 10 Enabled ●/● ● ● 6. 26. 7
 0610 Low current trip selection
0:No trip
1:Trip
1/1 0 Enabled ●/● ● ● 6. 26. 7
 0611 Low current detection current 0~100% 1/1 0 Enabled ●/● ● ● 6. 26. 7
 0612 Low current detection time 0~255 sec. 1/1 0 Enabled ●/● ● ● 6. 26. 7
 0613 Selection of short circuit detection at starting
0:Each time (standard pulse)
1:Only one time after power is turned on
2:Each time (short pulse)
3.Only one time after power is turn on (short
pulse)
4:Each time (Extremely shot-time pulse)
5.Only one time after power is turn on (Extremely
shot-time pulse)
1/1 0 Disabled ●/● ● ● 6. 26. 8
 0615 Overtorque trip selection
0:No trip
1:Trip
1/1 0 Enabled ●/● ● ● 6. 26. 9
 0616
Overtorque detection level during power
running
0~250% 1/0.01 150 Enabled ●/● ● ● 6. 26. 9
 0617
Overtorque detection level during
regenerative braking
0~250% 1/0.01 150 Enabled ●/● ● ● 6. 26. 9
 0618 Overtorque detection time 0.00~10.00 sec. 0.01/0.01 0.50 Enabled ●/● ● ● 6. 26. 9
 0619 Overtorque detection hysteresis 0~100% 1/0.01 10 Enabled ●/● ● ● 6. 26. 9
 0620 Cooling fan control selection
0:Auto
1:Always ON
1/1 0 Enabled ●/● ● ● 6. 26. 10
 0621 Cumulative operation time alarm setting 0.1~999.9 (x100h) 0.1/0.1 610.0 Enabled ●/● ● ● 6. 26. 11
 0622 Abnormal speed detection time 0.01~100.0 sec. 0.01/0.01 0.01 Enabled
●/● ● ●
6. 26. 12
 0623 Overspeed detection frequency upper band 0.0:Disabled, 0.1~30.0Hz 0.1/0.01 0.0 Enabled
●/● ● ●
6. 26. 12
 0624 Overspeed detection frequency lower band 0.0:Disabled, 0.1~30.0Hz 0.1/0.01 0.0 Enabled
●/● ● ●
6. 26. 12
 0625 Undervoltage detection level 50~79%, 80: (auto mode) 1/1 80 Disabled ●/● ● ● 6. 26. 14
 0626 Overvoltage limit operation level 100~150% 1/1 134 Disabled ●/● ● ● 6. 15. 2
 0627 Undervoltage trip selection
0:Disabled
1:Enabled
1/1 0 Disabled ●/● ● ● 6. 26. 14
 0629 Regenerative power ride-through control level 55~100% 1/1 75 Disabled ●/● ● ● 6. 26. 15
 0631 Temperature detection
0:Standard (120%-60 sec.)
1:Estimation of temperature
1/1 0 Disabled - - - 5. 14
 0633
VI/II analog input wire breakage detection
level
0:None
1~100%
1/1 0 Enabled ●/● ● ● 6. 26. 16
