E6581386
A-6
1
Use crimped ring
lugs of appropriate
size on input and
output cables. Attach
to the top side of the
terminal block only.
Do not place wires
in the hole of the
terminal block.
M12 screw
Shorting-bar
Grounding capacitor switching switch
Grounding terminal
(M8 screw)
Screw hole for EMC plate
Grounding terminal
(M12 screw)
Groundin
g
terminal
(
M10 screw
)
M12 screw
Grounding capacitor
switching bar
M10 screw
M8 screw
Groundin
g
terminal
(
M10 screw
)
M12 screw
Grounding capacitor
switching bar
M10 screw
M8 screw
M4 screw
VFPS1-2550P, 2750P
VFPS1-4900PC, 4110KPC
VFPS1-2900P
VFPS1-4132KPC
VFPS1-2300PM~2450PM
VFPS1-4450PL~4750PL
