TP-Link Archer C3200 - Page 18

Archer C3200 AC3200 Wireless Tri-Band Gigabit Router
)
)
Note:
If your Internet connection is through an Ethernet cable from the wall instead of through a
DSL / Cable / Satellite modem, connect the Ethernet cable directly to the router’s Internet
port.
2. Verify that the following LEDs are on and stable before continuing with the configuration:
)
Note:
If the 2.4GHz, 5GHz-1, and 5GHz-2 LEDs are off, press the Wi-Fi button
for about 2
seconds, then check the LEDs again in a few seconds.
3. Connect your computer to the router.
Option 1: Wire
d
T
urn off the Wi-Fi on your computer and connect the devices as shown below.
- 7 -
