TP-Link Archer C3200 User Manual

Archer C3200 AC3200 Wireless Tri-Band Gigabit Router
To change the mode or channel:
Go to Advanced > Wireless >Wireless Settings page and select the wireless network 2.4GHz
or 5GHz.
¾ Mode: Select the desired mode.
802.11n only: Select only if all of your wireless clients are 802.11n devices.
802.11gn mixed: Select if you are using both 802.11b and 802.11g wireless clients.
802.11bgn mixed: Select if you are using a mix of 802.11b, 11g, and 11n wireless clients.
Note: When 802.11n only mode is selected, only 802.11n wireless stations can connect to the
router. It is strongly recommended that you select 802.11bgn mixed, and all of 802.11b, 802.11g,
and 802.11n wireless stations can connect to the router.
802.11ac/n mixed (5Ghz) - Select if you are using both 802.11ac and 802.11n wireless
clients.
802.1111a/n/ac mixed (5Ghz) - Select if you are using a mix of 802.11ac, 802.11n and
802.11ac wireless clients. It is strongly recommended that you select 11a/n/ac mixed.
¾ Channel: Select the channel you want to use from the drop-down list. This field
determines which operating frequency will be used. It is not necessary to change the
wireless channel unless you notice interference problems with another nearby access
point.
¾ Channel Width: Select the channel width from the drop-down list. The default setting is
automatic, which can adjust the channel width for your clients automatically.
To change the security option
˖
˖
1. Go to Advanced > Wireless >Wireless Settings page.
2. Select the wireless network 2.4GHz or 5GHz.
3. Select an option from the Security dropdown list. The router provides four options, None,
WPA/WPA2 Personal (Recommended), WPA/WPA2 Enterprise, WEP. WPA2 uses the
newest standard and the security level is the highest. We recommend you don’t change the
default settings unless necessary.
13.2.2 Use WPS for Wireless Connection
You can use WPS feature to add a new wireless device to an existing network quickly.
1. Visit http://tplinkwifi.net, and log in with the password you set for the router.
2. Go to Advanced > Wireless >WPS page.
3. Select the wireless network 2.4GHz or 5GHz according to your wireless client.
- 70 -

TP-Link Archer C3200 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Firewall security	Domain Filter, IP Address Binding, MAC Address Binding
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
VPN support	PPTP, L2TP, IPSec
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	5GHz: 11a 6Mbps: -94dBm 11a 54Mbps: -76dBm 11ac HT20: -68dBm 11ac HT40: -64dBm 11ac HT80: -60dBm 2.4GHz 11g 54M: -77dBm 11n HT20: -73dBm 11n HT40: -71dBm
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Number of WLAN connections (max)	4
WLAN data transfer rate (third band)	600 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Link, Power, WLAN
Housing material	Plastic
USB 2.0 ports quantity	1
Output current	5 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, FCC, RoHS
Antennas quantity	6
Cables included	LAN (RJ-45)
Package type	Box

Weight and Dimensions

Width	200 mm
Height	39 mm
