Archer C3200 AC3200 Wireless Tri-Band Gigabit Router
4. Select the Enable DMZ checkbox.
5. Enter the PC’s IP address 192.168.0.100 into the DMZ Host IP Address
field.
6. Click Save.
Completed!
1. If Method 1 Virtual Server is used, the Internet users can enter http:// WAN
IP: External Port (in this example: http:// 218.18.232.154: 8000) to visit your
personal website.
2. If Method 2 DMZ is used, the Internet users can enter http:// WAN IP (in this
example: http:// 218.18.232.154) to visit your personal website.
Tip: Please make sure your WAN IP is a public IP address. As the WAN IP
address is dynamic, you are suggested to register a domain name for your
router, then visit the website using http:// domain name: External Port.
12.2 Share Local Resources on the Internet
I want to:
Make my office PC visit and download the files and resources in the home PC
through the Internet.
For example: The home PC is connected to the home router, whose WAN IP
address is 218.18.232.154. The FTP server has been built in the home PC.
Other PCs in the LAN can visit and download the files in the FTP server. Now I
want my office PC connected to the Internet to get the files and resources from
the FTP server.
How can I
do that?
Tip: Two methods are introduced in this section. “Method 1 Though Virtual
Servers” is relatively more complex to configure but with higher security while
“Method 2 Through DMZ” is easier to configure but with lower security. Please
choose the proper method in accordance with your actual need.
Method 1 Through Virtual Server
1. Check to see the IP address of your PC. Take 192.168.0.100 as an
example. The port of FTP service is 21.
Tip: The port varies in different service. Please verify the IP address of the
- 58 -
